| ENGINE |
| Type |
2 cylinder, water cooled engine |
| Engine capacity (cc) |
702 |
| Max engine output |
16 Hp @ 3200 rpm |
| Max engine torque |
38 Nm @ 2000 rpm |
| Fuel tank capacity (ltrs) |
30 |
| TRANSMISSION AND STEERING |
| Clutch |
Single plate dry friction diaphragm type |
| Gearbox |
GBS 65-4 / 6.31 |
| Type |
4 speed manual transmission |
| Steering |
Mechanical steering |
| SUSPENSION |
| Front |
Parabolic leaf spring |
| Rear |
Parabolic leaf spring |
| Shock absorber |
Hydraulic double acting telescopic type |
| BRAKES |
| Front |
Disc brakes |
| Rear |
Drum brakes |
| WHEELS & TYRES |
| Type |
145 R12 LT 8PR RADIAL |
| DIMENSIONS |
| Wheelbase (mm) |
2100 |
| Vehicle dimensions (l*b*h) (mm) |
3800 x 1500 x 1845 |
| Cargo box dimensions (l*b*h) (mm) |
2140 x 1430 x 300 |
| WEIGHTS |
| GVW (Kg) |
1550 |
| Payload (Kg) |
710 |
| PERFORMANCE |
| Grade ability |
22% |
| Top speed (kmph) |
60 |
