ENGINE |
Model |
Cummins ISLe 375 |
No. of cylinders: |
6 |
Capacity (cc) |
8898 |
Max engine output |
375 PS @ 2100 rpm |
Max engine torque |
1550Nm @ 1200-1400rpm |
Clutch (mm) |
430 |
GEAR BOX |
Type |
Eaton FSO 10309 OD |
No.of Gears |
9 Forward, 1 Reverse |
FrontAxle |
Heavy Duty forged āIā beam reverse
Elliot type |
REAR AXLE |
Type |
TATA RA-210 HRT Hub reduction |
Ratio |
5.492 |
Steering |
LHD, integral Hydraulic power steering, tilt
& telescopic type |
SUSPENSION |
Type |
Parabolic leaf spring at front & Two spring
balance beam bogie with semi elliptic
multi leaf spring & rubber mounted torque
rods and V-Rods at Rear |
Shock Absorber |
Hydraulic double acting telescopic type at
front only |
BRAKES |
Service Brakes |
Full Air Dual Circuit S-Cam with ABS |
Parking Brake |
Jake Brake with Auto Slack adjuster |
WHEELS AND TYRES |
Tyres |
315/80 R 22.5 |
Wheel Rims |
9×22.5 rim 10 holes |
No. of Wheels |
Front-2, Rear ā 8, Spare- 1 |
FUEL TANK |
Capacity (Litres) |
625 (365+260) |
Cabin |
Full Forward Prima tilt Cabin with HVAC,
2 sleeping berth, pneumatic driver seat
and mechanical adjusted co-driver seat |
ELECTRICAL SYSTEM |
Battery |
12V, 150Ahx2 nos |
Alternator |
28V, 90Amps |
System Voltage |
24 Volts |
DIMENSIONS |
Wheelbase (mm) |
4275 |
Max. Width (mm) |
2585 |
Overall Length (mm) |
7355 |
Turning Circle Dia. (mm) |
17220 |
PERFORMANCE |
Maximum Speed (kmph) |
103 |
Maximum Gradability in Crawler Gear |
18% |
WEIGHTS |
Kerb weight (approx.)(Kg) |
10120 |
Max. Pemissible FAW (Kg) |
7500 |
Max. Pemissible RAW (Kg) |
25500 |
Max. Pemissible GVW (Kg) |
60000 |
FIFTH WHEEL COUPLING |
King pin offset(mm) |
320 |
Size (mm) |
7500 |
