| ENGINE |
| Engine Type |
Tata 697 TCIC |
| Engine capacity (cc) |
5675 |
| Power |
128 Hp@ 2400 rpm |
| Torque |
416 Nm @ 1400 – 1700 rpm |
| CLUTCH |
| Type |
Single plate dry friction type |
| Outside Diameter (mm) |
310 |
| GEARBOX |
| Model |
GBS – 40 Synchomesh |
| No.of Gears |
5 F + 1 R |
| STEERING |
Power steering |
| SUSPENSION |
| Type |
Semi elliptical leaf spring at front
and rear |
| Anti-roll Bar |
At front and rear |
| BRAKES |
| Service Brakes |
Dual circuit full air S-cam brake |
| Parking Brake |
Spring actuated parking brake acting on
rear wheels |
| Engine Exhaust Brake |
Coupled with service brake |
| Front / Rear Type |
Drum / Drum |
| WHEELS AND TYRES |
| Tyres |
7.5 R 16 – 14 PR |
| No. of Wheels |
Front: 2, Rear: 4, Spare: 1 |
| Fuel Tank (Litres) |
120 |
| ELECTRICAL SYSTEM |
24 Volts |
| PERFORMANCE |
| Max. Gear in Top gear (kmph) |
112 |
| Max. Gradability in 1st Gear |
31% |
| Min. Turning Circle Diameter |
13.5 |
| DIMENSIONS |
| Wheelbase (mm) |
3800 |
| Track- Front / Rear (mm) |
1650 / 1577 |
| Overall Bus Length (mm) |
7510 |
| Overall Bus Width (mm) |
2200 |
| Overall Height (mm) |
2800 |
| Max. Permissible FAW (kgs) |
2800 |
| Max. Permissible RAW (kgs) |
4700 |
| Max. Permissible GVW (kgs) |
7500 |
| SEATING CAPACITY-DOOR |
| 28+1 seats (2×2 layout) |
1 door , 28+5 jump seats+1 – 1 door, |
| 24+1 seats (peripheral seating) |
1 door, 26+1 seats -2 door |
| AC / Non AC |
Available in AC / Non AC |
